Astro

FOUNDATION SERIES LED HIGHBAY

✓ High output up to 30,000lm @ 200W
✓ Long >60,000 hours life
✓ High efficacy of 150lm/W
✓ Quality Lumileds LED chips
✓ Flexible wattage select options (100W/150W/200W)
✓ Low profile design
✓ 3CCT selectable (4000k/5000K/6000K)
✓ Emergency version
✓ 3m Flex and Plug

see Detailed specs
HIGH

150lm/W

EFFICACY
LONG

>60,000HRS

LIFETIME
UP TO

30,000LM

OUTPUT
FLEXIBLE

3CCT

SWITCHING
Feature

3CCT Selectable

Flexible colour temperature options at the flick of a switch. Choose from commercial friendly options 4000K/5000K/6000K

Specifications

Filter all product variations
ASTRO-200-8456-90
200W
100W/150W/200W
4000K/5000K/6000K
100W (15,000lm), 150W (22,500lm), 200W (30,000lm)
150lm/W
>80
>50,000hrs
SMD
<5
90°
28(200W) 28(150W) 25(100W)
AC200-240V / 50-60 Hz
>0.95
Full specifications
Default Wattage
200W
Wattage Options
100W/150W/200W
CCT Options
4000K/5000K/6000K
Lumen Output @ 4000K
100W (15,000lm), 150W (22,500lm), 200W (30,000lm)
Luminaire Efficacy
150lm/W
CRI
>80
Lifetime - TM21 L70
>50,000hrs
Light Source
SMD
SDCM
<5
Beam Angle
90°
UGR Rating
28(200W) 28(150W) 25(100W)
Mains Voltage
AC200-240V / 50-60 Hz
Power Factor
>0.95
THD
<10%
Driver Lifetime
>50,000hrs
Control
1-10V
Body Material
Aluminium
Lens Material
Polycarbonate
Body Colour
Black
Dimensions
Ø320x113
Weight
2kg
IP Rating
IP66
IK Rating
IK08
Operating Temp
-20º to +45ºC
Protection Class
Class 1
Certifications
SAA
Warranty
5 Year product replacement
Stocked
Yes
Downloads
pdf
Evolve Astro Highbay Spec Sheet
ies
ASTRO-200-8456-90 (200W 4000K)
ies
ASTRO-200-8456-90 (150W 4000K)
ies
ASTRO-200-8456-90 (100W 4000K)
