Sky Panel PRO
LOW GLARE LED PANEL LIGHT
✓ Low Glare UGR19 rating
✓ CRI>90 & R9>50 for excellent colour rendering
✓ Smooth, even light distribution
✓ Long lasting, >60,000 hours lifetime
✓ Flicker-free
✓ Dimming options available
✓ 1.2m Flex and plug included

LOW
UGR<19
GLARE RATING
EXCELLENT
CRI>90
COLOUR RENDERING
LIFETIME OF
60,000+
HOURS TO L80
HIGH
100lm/W
SYSTEM EFFICACY

Feature
A Comfortable Lighting Solution
The light output of LED panels has increased over the last few years, also causing a rising issue of glare within workplaces. Evolve’s low glare panels tackle this problem by utilising an excellent UGR rating of <19. A micro prismatic diffuser refocuses the light downwards, out of direct eyesight, creating a more comfortable environment with minimal glare.

A Kit for Everything
Whether your Sky Panel PRO needs to be suspended, surface mounted, or recessed; we have the solution for you.
Family specifications and downloads
Download family spec sheetpdf • 905.43 KB

- skypro6060-36-940-lg
- 600x600mm
- 36W
- 3,600lm (+/-5%)
- 100lm/W
- 4000K
- >90
- 90°
- AC200-240V / 50-60Hz
- Yes
- IP40
- Triac / DALI, SwitchDim, 1-10V
- 5 year product replacement

- skypro1230-36-940-lg
- 1200x300mm
- 36W
- 3,600lm (+/-5%)
- 100lm/W
- 4000K
- >90
- 90°
- AC200-240V / 50-60Hz
- Yes
- IP40
- Triac / DALI, SwitchDim, 1-10V
- 5 year product replacement

- skypro1260-50-940-lg
- 1200x600mm
- 50W
- 5,000lm (+/-5%)
- 100lm/W
- 4000K
- >90
- 90°
- AC200-240V / 50-60Hz
- Yes
- IP40
- DALI, SwitchDim, 1-10V
- 5 year product replacement
Specifications
Filter all product variations
Light Colour
Controls
Size
PRODUCT CODE
Size
CCT
System Wattage
Lumen Output
Luminaire Efficacy
Lifetime - L70
CRI
SDCM
Beam Angle
UGR
Power Supply
Mains Voltage
Power Factor
SKYPRO1230-36-940-LG
1200x300mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
1200x300mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
Fixed Output
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
1196mm
Width
296mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO1230-36-940-LG-DIM
1200x300mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
1200x300mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
DALI, SwitchDim, 1-10V
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
1196mm
Width
296mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO1230-36-940-LG-PC
1200x300mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
1200x300mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
Phase Cut
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
1196mm
Width
296mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO1260-50-940-LG
1200x600mm
4000K
50W
5,000lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
1200x600mm
CCT
4000K
System Wattage
50W
Lumen Output
5,000lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
Fixed Output
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
1196mm
Width
596mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO1260-50-940-LG-DIM
1200x600mm
4000K
50W
5,000lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
1200x600mm
CCT
4000K
System Wattage
50W
Lumen Output
5,000lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
DALI, SwitchDim, 1-10V
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
1196mm
Width
596mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO6060-36-940-LG
600x600mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
600x600mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
Fixed Output
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
596mm
Width
596mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO6060-36-940-LG-DIM
600x600mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
600x600mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
DALI, SwitchDim, 1-10V
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
596mm
Width
596mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
SKYPRO6060-36-940-LG-PC
600x600mm
4000K
36W
3,600lm
100lm/W
>54,000hrs
>90
<3
90º
19
High efficiency LED driver
AC200-240V / 50-60Hz
>0.90
Full specifications
Size
600x600mm
CCT
4000K
System Wattage
36W
Lumen Output
3,600lm
Luminaire Efficacy
100lm/W
Lifetime - L70
>54,000hrs
CRI
>90
SDCM
<3
Beam Angle
90º
UGR
19
Power Supply
High efficiency LED driver
Mains Voltage
AC200-240V / 50-60Hz
Power Factor
>0.90
THD
<15%
Connection
1.2m Flex and plug
Control
Phase Cut
Flicker Free
Yes
Body Material
Aluminium
Lens Material
PMMA / PS
Finish
Powder Coated
Colour
White
Seismic Restraints
Yes (2m Stainless cable)
Length
596mm
Width
596mm
Height
30mm
IP Rating
IP40
IK Rating
IK04
Operating Temp
-20º to +45ºC
Protection Class
Class 2
Warranty
5 Year Product Replacement
Stocked
Yes
Downloads
